0.05-2.52mm High Speed Unilay Buncher Wire and Cable Making Bunching Buncher Twisting Machine
-
12months
-
200kg
-
From 1.0mm-3.0mm
-
500/630 Bobbin
-
Belt Brake When Wire Break
-
Core Wire Pay off or Workwith Single Twist Machine
Series for frame type single twist(cable laying)machine
Technic parameters:Equipment model F C-630 FC-800 FC-1000 FC-1250 Usage It is applied to the twisting of PVC/PE core wire or copper wire,central bundling or side bundling Applied for wire(mm) φ0.6-3.0 φ0.6-3.0 φ1.0-6.0 φ1.0-6.0 Max twist outer dia(mm) φ12 φ16 φ25 φ30 Pitch(mm) 10-150 30-200 50-300 50-400 Direction of lay Optional for right or left Take up bobbin size Φ630 φ800 φ1000 φ1250 Max rotating speed(rpm) 600 500 500 400 Traverse type Traverse is adopt crossbar-less reciprocating Take up tension Pneumatic tension automatic regulate Brake type Disk brake Bundling type Central bundling or side bundling Replace pitch type Computer pitch or gear pitch
Series for frame type single twist(cable laying)machine
Technic parameters:Equipment model F C-630 FC-800 FC-1000 FC-1250 Usage It is applied to the twisting of PVC/PE core wire or copper wire,central bundling or side bundling Applied for wire(mm) φ0.6-3.0 φ0.6-3.0 φ1.0-6.0 φ1.0-6.0 Max twist outer dia(mm) φ12 φ16 φ25 φ30 Pitch(mm) 10-150 30-200 50-300 50-400 Direction of lay Optional for right or left Take up bobbin size Φ630 φ800 φ1000 φ1250 Max rotating speed(rpm) 600 500 500 400 Traverse type Traverse is adopt crossbar-less reciprocating Take up tension Pneumatic tension automatic regulate Brake type Disk brake Bundling type Central bundling or side bundling Replace pitch type Computer pitch or gear pitch
