0.05-16.0mm Insulated Cable Wire Extruder Extrusion Sheathing Electrical Cable Wire Making Machine
-
12months
-
PP,PE,PVC Extruder
-
PE
-
Extrusion Molding Machine
-
Multiple Feed
-
Single-Screw
Parameters of FC-70+40extrusion machine
φ70+φ40 high speed extrusion machine(Touch screen operation)- It is mainly for low halogen and PVC plastic material extrusion for electric wire and cable wire.
- Operation direction:right hand machine or left hand machine
- Main machine centre height 1000mm;
- Inlet wire:φ0.6-φ3.2mm;
- Finished wire:φ1.5-φ5.0mm;
- Production linear speed:350m/min
- Main machine color:main machine RAL5012 sky blue; electric cabinet: computer white;safe color:yellow.
- Machine composition
No Name Numbers Unit Note 1. 630 active pay off 1 Pcs Fuchuan made 2. 120 swing tension rack 1 Pcs Fuchuan made 3. Wire straightening 1 Pcs Fuchuan made 4 U7 head 1 pcs ShangHai Xu Dong 5 ¢70 main machine 1 pcs Fuchuan Made(contain ZhouShan PVC screw one set) 6 ¢40movable injection machine 1 pcs Fuchuan made 7 1.8 meters movable cooling water tank 1 set Fuchuan made 8 Diameter measure device 1 set ShangHai On-line 9 High speed printer 1 pcs Customer provide 10 Front two meters back six meters single layer cooling water tank 1 set Fuchuan made 11 510hauling machine 1 pcs Fuchuan made 12 510sub hauling machine 1 pcs Fuchuan made 13 12meters horizontal accumulator rack 1 set Fuchuan made 14 159 meter counter 1 Pcs Fuchuan made 15 Spark tester 1 Pcs Tai Wan He Tai 16 630double shaft take up machine 1 pcs 17 Dry hopper loader(for 70extruder) 1 set Tai Wan Shin Yi 18 Suction machine(for 70extruder) 1 set Tai Wan Shin YI 19 Electric-control part
1
set
