0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine

Availability:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

  • 12months

  • Copper Wire and Alloy Wire Annealing Tinning

  • 0.03-0.08

  • 0.016-0.05mm

  • Nitrogen Protection or Vapour Protection

  • Hot DIP

The technology of this machine is brought from Japan and put in production in JiangSu.
Merits: Easy to operate, good annealing heat preservation, save electricity, achieve industry-leading level

Equipment models: FC-T16
Twisting usage: It is applied to the annealing and tinning of ultra-fine round copper wire and alloy wire.

Inlet wire dia(mm): φ0.08-φ0.25mm or φ0.15-φ0.64mm
Max numbers of inlet wire : 16pcs
Linear speed : max:300m/min
Pay off method : Brush pay off
Pay off bobbin model: φ300bobbin
Annealing furnace length: 3.5m or 6m
Annealing method: tube annealing
Annealing protection method: water seal protection
Tinned method: Hot dip
Capstan control method : Inverter+ Motor control or adopt stepless speed regulation motor
Equipment total power: 53KW
Take up control: Take up is voltage regulator control the moment motor
Take up bobbin size: 5 inch,8 inch bobbin or 5 inch. 8 inch,10 inch bobbin.
Traverse control method: stepless speed regulation motor + Turbine gear box control toothrow traverse
Dimension: 14500L*1500W*2100H

0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine
0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine
0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine
0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine
0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine

0.03-0.64mm Copper Cable Wire Annealing Annealer Tinning Winding Making Bunching Bunchers Machine
