0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine

Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • 12months

  • Dia 0.6-3.0

  • FC-630/800/1000/1250

  • Sky Blue

  • PVC/PE Core Wire or Copper Wire

  • Disc Brake


0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine

0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine
0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine
0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine
0.05-0.64mm Copper Wire High Speed Unilay Bunching Machine Buncher Machine Double Twist Winding Stranding Making Twisting Machine Cable Drawing Machine


Usage:It is applied to the twisting of PVC/PE core wire or copper wire,central bundling or side bundling.


A.FC-800frame type single twist bunching machine
1. Main equipment parameters:
Machine usage:It is mainly used in laying up of insulated core, such as data cable and control cable. It may synchronize central coil tapping and side coil tapping. The entire machine is consists of pay off rack, central bundler, side pay off rack for the central coil tapping set, single twist(cable-laying) machine and electrical control cabinet. Fit for PVC coated centre bundling and twisting, copper wire re-twisting.
2. FC-800 frame type single twist bunching machine
2.1 single core wire¢0.9mm-¢3.0mm
2.2 Main machine max rotating speed:500rpm
2.3 Twisting pitch:30-200mm
2.4 Max twisting outside diameter: ¢15mm
2.5 Max hauling speed:500r/min
2.6 Main machine centre height: 800mm
2.7 Total power:11KW
2.8 Max speed of central bundling machine :2600m/min
2.9 Cable sq.mm from 0.14sq.mm to 1.5sq.mm
3.0 Over all cable OD-2MM to 12mm
3.1 Lay length adjustment by PLC

3.Main components:
3.1 FC-800 main machine 1set
3.2 FC-800 center bundling machine 1set
3.3 Wire concentration seat 1set
3.4 Electrical control cabinet 1set
3.5 FC-630 core wire pay off rack 6heads/set*1set
