0.05-0.64mm Tinned Copper Wire, Stranding Bunching Twisting Twister Buncher Machine
-
12months
-
Electric
-
New
-
ISO
-
12 Months
-
Automatic
FC-400B High speed bunching machine parameters:
Main performance parameters of FC-400B high speed bunching machine (replace of the capstan wheel to change the lay length).2.Diameter of single core: φ0.08~φ0.25mm
1.Usage:It is applied to the stranding of bare twisted wire,tinned,copper covered aluminum,lacquer wire,enamelled wire and alloy wire. 1+6 may bunching instead of twisting.
3.Outer diameter of wire: φ0.15~φ1.30mm
4.Cross section area: φ0.0137~φ1.0mm2
5.Size of take up spool: φ400mm×length300mm×inner coreφ56mm(according to client's drawings to make).
6. Maximum rotating speed: 3000RPM
7.Type of traverse: φ15mm rolling ring traverse, winding pitch and breadth are adjustable.
FC-400B High speed bunching machine parameters:
Main performance parameters of FC-400B high speed bunching machine (replace of the capstan wheel to change the lay length).2.Diameter of single core: φ0.08~φ0.25mm
1.Usage:It is applied to the stranding of bare twisted wire,tinned,copper covered aluminum,lacquer wire,enamelled wire and alloy wire. 1+6 may bunching instead of twisting.
3.Outer diameter of wire: φ0.15~φ1.30mm
4.Cross section area: φ0.0137~φ1.0mm2
5.Size of take up spool: φ400mm×length300mm×inner coreφ56mm(according to client's drawings to make).
6. Maximum rotating speed: 3000RPM
7.Type of traverse: φ15mm rolling ring traverse, winding pitch and breadth are adjustable.
