0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine


Availability:



Inquire Add to Basket

Driven Type:
Electric
Condition:
New
Certification:
ISO, CE
Warranty:
12 Months
Automatic Grade:
Automatic
Mould Life:
300,000-1,000,000 Shots

Product Description

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

0.05-2.52mm Tinned Wire, Core Wire, Copper Conductor Wire Twisting Twister Bunching Buncher Coiling Machine

Main performance parameters of FC-800B automatic high speed bunching machine (replace of the capstan wheel to change the lay length).

Equipment model	FC-500B	FC-650B	FC-650B modified	FC-800B
Twisting usage	Apply for the twisting of above seven pcs of bare copper wires,tinned wires,silver jacketed wires and enamelled wires)double twisting for core wire
Single wire dia(mm)	0.08-0.45	0.15-1.04	0.38-1.7	0.38-1.7
Stranding section area	0.05-2.5	0.35-6.0	1.0-16
Core wire dia	0.5-1.5	0.5-3.0	1.5-4.0	1.5-4.0
Twisted outer dia	1.0-3.0	1.6-6.0	3.0-8.0
pitch	6.3-52.3	11.6-100	20-160	23-160
Direction of lay:free option to S Z
Take up size	400-500	500-630		630-800
Max speed	3000(6000TPM)	2000(4000TPM)	1600(3200TPM)
power	5.5KW	7.5KW	11KW	15KW
Tension control method:touchscreen+PLC+magnetic powder clutch,ensure constant tension from empty to full bobbin
Magnetic powder	1.2kgf	5kgf	10kgf	10kgf
protection	Internal and outer wire cut off automatic brake(electromagnetic brake).automatic shut down when the meters reaches
Traversing method	Precious traverse or screw type polish wire traverse,winding pitch and width are adjustable

For more details, please feel free to contact me.
